    Electropneumatic Positioner Control Valve Positioner With HART Communication

    Ask Lasest Price
    Brand Name : Samson
    Model Number : 3767
    Price : 1590USD~2000USD
    Payment Terms : T/T
    Supply Ability : 100 Sets/Month
    Delivery Time : 4~8 working weeks
    • Product Details
    • Company Profile

    Electropneumatic Positioner Control Valve Positioner With HART Communication

    Product Description:

    The equipment can be mounted in any position which makes it very versatile. It is suitable for both normal and split-range operation which provides flexibility when it comes to control. The dynamic response it offers is excellent, which gives precise and quick control over the process. Additionally, it has a negligibly small influence on the supply air, making it reliable and predictable.

    The proportional band is adjustable, which gives the user complete control over the process. The air output capacity is also adjustable, which provides even more flexibility to the user. It has low air supply consumption which makes it energy efficient. The equipment is not affected by mechanical vibrations which makes it a reliable option for industrial use.

    The design of the equipment is compact which means it does not take up much space, making it ideal for installation in tight spaces. It also requires low maintenance, which makes it a cost-effective option in the long run.

    Features:

    Overview of Electropneumatic Positioner

    Our Electropneumatic Positioner offers precise and reliable control of linear and rotary actuators. Its die-cast aluminum or stainless steel housing provides optimal durability and resistance to environmental factors for long-lasting performance. The positioner can be attached to linear actuators according to IEC 60534-6 or SAMSON integral attachment, and to rotary actuators according to VDI/VDE 3845.

    Features of Electropneumatic Positioner

    Our Electropneumatic Positioner features a compact and low-maintenance design that can be mounted in any position. The positioner is also insensitive to mechanical vibrations, ensuring the accuracy of the control signal. Additionally, its direction of action is reversible, providing more flexibility in installation. The positioner also boasts excellent dynamic response for fast and precise control. Normal and split-range operation can also be easily achieved with adjustable proportional (P) band. Furthermore, our positioner has an adjustable air output capacity and a low supply air consumption.

    Attachment and Compatibility

    The Electropneumatic Positioner is compatible with double-acting actuators with Type 3710 Reversing Amplifier. It can be attached to different types of actuators and control valves, providing versatile control options. With its reliable performance and adaptable design, our Electropneumatic Positioner is perfect for use in various industrial applications that require precise and efficient control over actuators.

    Technical Parameters:

    Product AttributeValue
    DiagnosticsWithout
    ActingSingle Acting or Double Acting
    ActuatorLinear or Rotary
    CommunicationWithout
    MaterialAluminum
    Product nameSamson 3767
    Customized supportOEM
    Warranty1 Year
    UsageChallenging Transit Times and Ambient Conditions
    Brand NameSamson

    Applications:

    Positioners are necessary attachments for pneumatic control valves, as they are responsible for ensuring the valve is in the correct position based on the signals it receives. These positioners are commonly available in two types: single-acting and double-acting positioners.

    Single-acting positioners rely on compressed air to either increase or decrease the valve actuator's air pressure. This movement causes the valve to either open or close based on the signal the positioner receives.

    Double-acting positioners also rely on compressed air, but they provide more precision in valve positioning. This is achieved through the use of a feedback mechanism in addition to the input signal. As a result, double-acting positioners are more commonly used in applications that require accurate and responsive control.

    Overall, both single-acting and double-acting positioners are essential components in ensuring effective and efficient pneumatic control valve operation.


    Packing and Shipping:

    Product Packaging:

    • The Control Valve Positioner will be packaged in a sturdy cardboard box.
    • The product will be wrapped in bubble wrap to prevent any damage during transit.
    • The box will also contain an instruction manual and any necessary mounting hardware.

    Shipping:

    • The Control Valve Positioner will be shipped via standard ground shipping.
    • The product will be shipped within 1-2 business days of receiving the order.
    • Customers will be provided with a tracking number to monitor the progress of their shipment.
