Electro-Pneumatic Positioner YTC TMP-3000 smart Digital Valve
Positioner for control valve
Product Introduction
TMP-3000 has a built-in filter that filters foreign substances from
the outside. During maintenance, please observe the followings to
clean the filter.
The TMP-3000 Smart Positioner not only precisely controls the valve
opening according to the electric input signal from the controller
or the central control room, but also performs the auto calibration
by the computation action of the built-in high performance
microprocessor and PD control. It is a highly reliable positioner
that performs various powerful functions such as optimum control.
Quick Details
| Place of Origin | Korea |
| Brand Name | YTC |
| Model Number | TMP-3000 |
| Diagnostics | 5 Pressure Sensors |
| Materials | Case/Cover: - Aluminum ASTM 360 |
| Welded | BW or SW |
| Operating Temperature | Standard Temperature |
| Screwed | NPT 1/4" through 2" (20 through 50 mm) |
| Body Materials | Cast iron PFA lined |
| Actuators | Model 35 spring-opposed rolling diaphragm |
| Trim | Eccentric rotary plug |
| inherent Characteristics | Linear |
➢ In case of Fail Freeze or Fail Safe optional product, it
maintains the current valve position without any additional
equipment such as lockup valve or solenoid valve in case of power
supply (24V) failure.
➢ Back light function LCD is attached so you can check the status
of the positioner directly in the field.
➢ Four adjustment buttons and unique functions of the buttons are
applied in the same way throughout the firmware, so it is very easy
to use.
➢ The initialization time is very short, which minimizes the change
of valve stroke in case of temporary power failure and improves
system stability.
➢ Very strong against vibration and can be used in extremely high
vibration areas.
➢ The change in supply pressure during use has almost no effect on
the adjustability of the positioner. ➢ Auto calibration is very
simple, so first time users can handle the product easily.
➢ Compact size makes it easy to attach to small actuators. ➢ Very
low air consumption which allows large plants to reduce their
operating costs.
➢ The valve system can be stabilized by outputting an analog
feedback signal. ➢ Different valve characteristics can be adjusted
– Linear, Quick Open, Equal Percentage, and User Set which user can
make 5 points or 21 points characterizations.
➢ You can minimize valve leakage by setting the sealing function of
Tight Shut-Off / On.
➢ Half-interval control (Split Range) is available such as 4 ~ 12mA
and 12 ~ 20mA etc..
➢ You can change Zero and Span freely through Hand Calibration
function.
➢ By manual operation, valve can be operated arbitrarily
irrespective of input signal, so it is easy to judge whether or not
there is an abnormality of valve. ➢ Ingress protection of IP67.
➢ The product's enclosure is made of a material with excellent
chemical resistance and moisture resistance, so it can be used
stably for a long time even in a corrosive atmosphere.
➢ The internal structure is very simple and modular, so there is
little possibility of failure and maintenance is simple.
➢ It is equipped with a foreign material prevention filter which is
easy to maintain.
➢ Flow rate can be selected according to actuator size.
➢ Solenoid valve with superior durability of over 200 million
cycles.
Specifications
Detailed Image
Packaging and Delivery
Export wooden boxes for foreign trade, IPPC sterilized wooden boxes
and plywood boxes for export customs inspection-free. Size:
60*30*40 (cm)
The products will be shipped after receiving the deposit or full
payment within 15 working days
Our Service
1. Swift delivery
For common parts, we can deliver the goods within 3 days
2. Original products
All the products we sell are from origin manufacturer. We will
submit all the manufacturer documentation while we finish delivery.
3. Quality Assurance
4. Technical Support
Including inspection, repair, and maintenance, we can give all
kinds of technical support.
5. Quickly response
Our staff will keep 24h online and answer your question very
quickly.
