    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator

    Ask Lasest Price
    Brand Name : SAMSON
    Model Number : 3241
    Price : negatiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50
    Delivery Time : 4-12 week
    • Product Details
    • Company Profile

    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator

    Product Description

    samson Control Valves 3241 globe valve with 3277 Pneumatic Actuator and 3725 positioner 4708 regulator


    VALVE STYLE Globe valve USAGE
    * Low-pressure service
    * Throttling service
    * Cryogenic service

    VERSION ANSI
    MEDIUM TEMPERATURE -196 to 425 °C / -320.8 to 797 °F
    SUPPLY Pneumatic
    VALVE SIZE NPS ½ to NPS 12
    PRESSURE RATING Class 125 to Class 300
    LINING without

    Options
    * Welding ends
    * Adjustable packing
    * Flow divider or AC-trim for noise reduction
    * Insulating section or bellows seal
    * Heating jacket
    * Perforated plug
    * Silencers


    Special features
    * Consisting of globe valve and actuator
    * Optionally including RFID transponder with unique marking according to DIN SPEC 91406


    Accessories
    * Type 2 N Strainer
    * Type 2 NI Strainer

    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator
    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator
    Specifications
    Reference variable
    4 to 20 mA
    Trave
    5 to 50 mm
    Opening angles
    24 to 100°
    Operating Temperature
    Standard Temperature
    Explosion protection
    Intrinsic safety: ATEX, STCC,
    Application
    Gas& Oil industry

    Special features

    Special features Type 3241 Globe Valve operated with
    • Type 3271 Pneumatic Actuator (Type 3241-1 Control Valve)
    • Type 3277 Pneumatic Actuator (Type 3241-7 Control Valve)
    Valve body made of
    • Cast iron
    • Cast steel, cast stainless steel or cast cold-resisting steel
    • Forged steel or forged stainless steel
    • Special materials Undivided valve bonnet up to NPS 6
    Valve plug
    •Metal seal
    • Soft seal
    • High-performance metal seal Optional with RF ID tags with one-to-one device marking according to DIN SPEC
    91406.
    The control valves with their modular design can be equipped with various accessories: Positioners, limit switches,
    solenoid valves and other accessories according to IEC 60534-6-1 1) and NAMUR recommendation. Refer to Information Sheet u T8350 for more details. Versions Standard version for temperatures ranging from 14 to 428 °F (–10 to +220 °C) – Type 3241-1 (Fig.1, Fig. 3) · NPS ½ to 12 · With Type 3271 Pneumatic Actuator (see Data Sheets u T 8310-1, u T 8310-2 and u T 8310-3) – Type 3241-7(Fig. 2, Fig. 4) · NPS ½ to 6
    · With Type 3277 Pneumatic Actuator for integral positioner attachment (see Data Sheet u T 8310-1

    Detailed Images
    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator
    Packing & Delivery
    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator
    Our Service
    Samson Control Valves 3241 Globe Valve With 3277 Pneumatic Actuator And 3725 Positioner 4708 Regulator

    1.Swift delivery
    For common parts, we can deliver the goods within 3 days

    2.Original products
    All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

    3.Quality Assurance

    4.Technical Support
    Including inspection,repair and maintenance, we can give all kinds of technical support.

    5.Quickly responce
    Our staffs will keep 24h online and answer your question very quickly.
